Standard Battery
Pro 40
A perfect fit for commercial vehicles and mobile machines
The Webasto Standard Battery Pro 40 is designed according to the highest safety and quality standards.
The modular and scalable concept is suitable as a traction battery for a wide range of vehicle types - from light commercial vehicles to various mobile machines.
Advanced battery technology
The Webasto Standard Battery Pro 40 is a successor product to the CV Standard Battery System and offers even more energy in the same installation space. Thus, it provides an even higher energy density for various vehicle applications.
Technical data Standard Battery Pro 40
| Technical specifications | Details |
| Dimensions (L x W x H) | 960 x 687 x 302 mm |
| Dry weight | 297 kg |
| Installed energy | ~ 40 kWh |
| Nominal capacity | 116 Ah |
Voltage range | 333 - 407 V |
| Energy density | ~ 232 Wh/l, > 135 Wh/kg |
| Continuous power (CH / DCH) (@25 °C, SoC dependent) | 45 / 55 kW |
Peak power (CH / DCH) (10 s, @25 °C, SoC dependent) | 60 / 112 kW |
| Lifetime (DoD, temperature and C-rate dependent) | Up to 3,000 cycles |
| Volume flow | 10 l/min |
| Pressure loss | < 50 mbar |
| Cell type | prismatic NMC |
| Operating temperature | -30 °C to +55 °C |
All advantages at a glance
- Scalable system with up to 18 Standard Battery Pro 40, a voltage of 400 or 800 V and with up to 720 kWh
- Robust housing enables use in rough terrain
- Intensively tested and certified to the highest safety and quality standards
- Vertical and horizontal mounting positions allow flexible and easy integration
- Convincing total cost of ownership thanks to standardized product
Safety features
- Physical separation between high voltage and cooling connectors
- Desiccant cartridges to avoid condensation over lifetime
- Integrated thermal runaway detection in each system
- State-of-the-art pressure equalization
- Insulation measurement, high voltage interlock and contactor monitoring included in every battery pack
- Temperature, voltage and current of different sub-components are monitored
