Efficient interface between battery system and vehicle

To ensure the scalability of the Standardized Battery System, Webasto offers two different interfaces: the Vehicle Interface Box (VIB) and the Vehicle Interface Gateway (VIG). Learn more about the advantages of both products and find the right choice for you.

Vehicle Interface Box (VIB)

The Vehicle Interface Box ensures the scalability of the Webasto Standardized Battery System.  It is not only a very efficient interface, but also combines the functions of power distributor, master BMS and fuses in one robust housing.  As the main control unit of the entire battery system, the VIB enables the connection of up to 10 Standard Battery Systems.  This creates a modular battery system that can be adapted to the requirements of many vehicle types.

Scalable system

The Vehicle Interface Box is the main control unit of the entire battery system and enables the connection of up to 10 Standarized Batteries at a system voltage of 400 or 800 Volt.

Highest safety standards

The Vehicle Interface Box was developed and produced as well as certified according to the highest safety standards. It also offers integrated safety protection and insulation measurement monitoring.

Charging infrastructure

The Vehicle Interface Box is designed for direct current charging (DC) and has a connector for onboard charger.

Robust housing

Thanks to its robust housing, the Vehicle Interface Box is designed to meet the requirements of commercial vehicles and mobile machinery. This allows it to be used individually in a wide variety of vehicle applications.

Technical data Vehicle Interface Box (VIB)

Technical specificationsDetails

Product dimensions (L x W x H)
548 x 686 x 155 mm
Weight42 kg
LV supply voltages12 and 24 V
HV supply voltages 400 & 800 V systems

Scalable energy with

CV standard batteries

35 – 35 kWh (max. 10 packs)
Scalable powerup to 460 kW
Continuous current DCH 380 A
Continuous current CH OBC 67 A
Continuous current CH DC fast charging 200 A
Peak current DCH (30 sec.) 580 A
Peak current recuperation (30 sec.) 500 A
Operational temperature-40 to +85 °C
Vehicle Interface Box (VIB)

Technical specifications


  • Specially designed for the Standardized Battery System
  • Direct connection and integrated fuse protection for further loads
  • Designed to enable DC charging
  • Connection for onboard charger available (AC charging)
  • Developed for the special requirements of commercial vehicles
  • Configuration of up to 10 battery packs possible (2s5p, 1s5p)
  • Due to standard components allow easy customization
  • Intelligent switching concept and central battery pack balancing
  • Central coordination and monitoring of isolation measurement
  • Evaluation of the high voltage interlock
  • Cable protection for power trains and auxiliary components
  • All components with 800 V capability
  • Central communication interface to battery system
  • Seperate CAN communication for vehicle (vehicle and battery pack CAN)
  • Integrated master BMS function (one central control unit for vehicle implementation)

Vehicle Interface Gateway (VIG)

In addition to the powerful and intelligent Vehicle Interface Box, Webasto also offers the Vehicle Interface Gateway (VIG). This gives customers even more power for commercial vehicles and with more compact dimensions. This offers greater flexibility when combined with the Standardized Battery System and when used in a limited installation space. At the same time, customers remain flexible in the design of the Power Distribution Unit (PDU).

Scalable system

The Vehicle Interface Gateway is a small and flexible master BMS and allows interconnection of up to 18 batteries at a system voltage of 400 or 800 Volt.

High power output

With the Vehicle Interface Gateway, the maximum power of the battery system can be obtained and therefore it allows a high output power. There is no HV limitation.

Highest safety standards

The Vehicle Interface Gateway was developed and produced as well as certified according to the highest safety standards for the commercial vehicle market.

Technical data Vehicle Interface Gateway (VIG)

Technical specificationsDetails

Product dimensions (L x W x H) (mm)
33 x 106 x 314
Weight (kg)~0.45
LV supply voltages (V)12 and 24
HV compability (V)400 & 800 systems

Scalable energy with

CV standard batteries (kWh)

35 – 630 (max. 18 Packs)
Scalable power (kW)up to 1,109
Continuous current DCH (A)1,215
Continuous current CH (A)1,102
Peak current DCH (30 sec.) (A)1,400
Peak current CH (30 sec.) (A)1,400
Operational temperature (°C)-40 to +85
Vehicle Interface Gateway (VIG)

Technical specifications


  • Specially designed for the Webasto Standardized Battery System
  • Master BMS function (one central control unit for vehicle implementation)
  • Enables high power outputs with maximum number of battery packs thanks to no HV limitations
  • AC and DC charging possible with additional vehicle-side HV architecture
  • Up to 18 battery packs possible (individual configuration to be aligned with Webasto)
  • Intelligent switching concept and central battery pack balancing
  • Installation and housing specifications according to quick manual requirements
  • Central coordination and monitoring of isolation measurement on 400 V system
  • High voltage interlock monitoring on vehicle level possible
  • Central CAN communication interface between vehicle and battery system
  • Supports 12 and 24 V power supplies in one solution

Download your Datasheets

Datasheet Vehicle Interface Box (VIB)

Do you want to know more about our intelligent master BMS? Just download our data sheet.
Size
358 KB
Format
application/pdf
Download

Datasheet Vehicle Interface Gateway (VIG)

Small and flexible: Find out more about the Vehicle Interface Gateway in our data sheet.
Size
180 KB
Format
application/pdf
Download
