Advanced fresh air units

The compact fresh air units in the BlueCool F-Series from Webasto are the ideal addition to a chiller system on larger boats and yachts. The fresh air units supply filtered and cooled fresh outside air into the cabins. Stale air is extracted by the extract units and transported to the outside. An advanced control concept coordinates heating and cooling for ideal temperatures and humidity. These units have a simple, compact design.

Group picture of BlueCool F-Series air makeup units

Benefits of BlueCool F-Series

High cooling capacity

With a cooling capacity of up to 84 kBTU/h, the units are also suitable for large yachts.

Powerful blower

Efficient EC blowers with high back pressure resistance provide up to 2,000 m3/h of fresh and exhaust air.

Highly efficient filters

The devices are supplied with G3 filters as standard, but can be upgraded with high-quality F7 filters.

Product details

Product specification

Cooling capacity: 21 - 84 kBTU/h (6 - 25 kW)
Heating function possible
Nominal voltage: 230 V
Frequency: 50/60 Hz
Dimensions L x H x W (mm) / Dimensions L x H x W (inch)
- F500 FreshAir: 720 x 400 x 500 / 28.3 x 15.7 x 19.7
- F1000 FreshAir: 760 x 550 x 650 / 29.9 x 21.7 x 25.6
- F2000 FreshAir: 930 x 700 x 750 / 36.6 x 27.6 x 29.5
- F500 Extract: 320 x 320 x 320 / 12.6 x 12.6 x 12.6
- F1000 Extract: 450 x 450 x 450 / 17.7 x 17.7 x 17.7
- F2000 Extract: 600 x 600 x 600 / 23.6 x 23.6 x 23.6
Weight of the unit (kg) / Weight of the electronics box (kg)
- F500 FreshAir: 42 / 7
- F1000 FreshAir: 65 / 7
- F2000 FreshAir: 110 / 7
- F500 Extract: 25 / -
- F1000 Extract: 35 / -
- F2000 Extract: 60 / -

Model overview

F500 FreshAir
F1000 FreshAir
F2000 FreshAir
F500 Extract
F1000 Extract
F2000 Extract
