Pordoi
Modular integrated transport refrigeration systems
With the Pordoi series of transport refrigeration units, Webasto offers a fully integrated solution for the temperature control of perishable goods in commercial vehicles with cargo spaces of up to 18 m3. The modular concept enables adaptation to a wide range of vehicles and applications, as the system components such as evaporator, condenser and compressor, as well as a variety of accessories, can be combined for individually tailored solutions. Thanks to the fully integrated design, neither the external appearance nor the aerodynamics of the vehicle are negatively affected.
Depending on the required temperature range, Pordoi can be filled with the refrigerants R134a or R404A and cool with up to 3,660 watts. An optional electric motor is available for standby mode which can be operated at the preset temperature when connected to the mains even when the vehicle engine is switched off.
Benefits of Pordoi
Product details
Product specifications
- Refrigerant: R404A or R134a
- Nominal cooling capacity
- at 30 °C ambient temperature and 0 °C compartment temperature: between 1,565 and 3,660 W
- at 30 °C ambient temperature and -20 °C compartment temperature: between 1,206 and 1,926 W
- at 30 °C ambient temperature and +5 °C compartment temperature: between 1,539 and 3,101 W
- Nominal voltage: 12 V
- Dimensions
- Condenser unit: Depending on the application
- Evaporator unit L x W x H (mm): 660 x 500 x 157 (Pordoi 2000) / 900 x 500 x 157 (Pordoi 3000) / 1,000 x 500 x 157 (Pordoi 4000)
- Weight
- Condenser unit: Depending on application
- Evaporator unit (kg): 7.5 (Pordoi 2000) / 10.5 (Pordoi 3000) / 12.5 (Pordoi 4000)
Model overview
- Pordoi 2000
- Pordoi 3000
- Pordoi 4000
