Frigo Top 10

Integrated battery-powered transport refrigeration system up to 5 m³

Frigo Top 10 from Webasto is a fully integrated, battery-powered transport refrigeration system for vehicles with a cargo space volume of up to 5 m³. It is perfect for transporting perishable goods over long distances and, with up to 1,135 watts, ensures optimum temperatures for chilled and frozen goods (-20 to +10 degrees Celsius).



Frigo Top 10 is the perfect solution especially for smaller transport vehicles with an air-conditioning system, but no space for an additional compressor in the engine compartment. The design is slim and compact, with the compressor, motor and condenser located under the chassis.

Product picture of Frigo Top 10 refrigeration system

Benefits of Frigo Top 10

Easy installation and maintenance

Frigo Top 10 requires neither space in the engine compartment nor holes in the roof, which makes installation easy and saves space and fuel.

Energy efficiency

Automatic temperature control and defrost function allow for highly efficient cooling in all temperature ranges.

Battery-operated system

The cooling system is powered directly by the vehicle battery, thus eliminating the need for engine-driven compressors and providing an efficient power supply solution.

ATP-certified

Frigo Top 10 is certified in accordance with Accord Transport Perishable Foodstuffs (ATP), which guarantees the highest standards in the transportation of perishable foodstuffs.

Product details

Product specifications



  • Refrigerant: R404A (Frigo Top 10 I-ESG: R452A)
  • Nominal cooling capacity (according to ATP standard)
    • at 30 °C ambient temperature and 0 °C compartment temperature in W:
      1,022 (Frigo Top 10 I-E) / 1,108 (Frigo Top 10 I-ES) / 1,119 (Frigo Top 10 I-ESG)
    • at 30°C ambient temperature and -10 °C compartment temperature in W:
      722 (Frigo Top 10 I-E) / 776 (Frigo Top 10 I-ES) / 750 (Frigo Top 10 I-ESG)
    • at 30 °C ambient temperature and -20 °C compartment temperature in W:
      389 (Frigo Top 10 I-E) / 403 (Frigo Top 10 I-ES) / 352 (Frigo Top 10 I-ESG)
  • Nominal voltage: 12 V
  • Dimensions L x W x H (mm)
    • Condenser unit: 481 x 265 x 124
    • Evaporator unit: 660 x 530 x 158
    • Motor compressor: 465 x 455 x 240
  • Weight (kg):
    • Condenser unit: 2.9 (Frigo Top 10 I-ESG: 2.8)
    • Evaporator unit: 11.5
    • Motor compressor: 25.0

Model overview



  • Frigo Top 10 I-E
  • Frigo Top 10 I-ES
  • Frigo Top 10 I-ESG
