Rooftop air-conditioning
systems 8.5 - 15.5 kW
Efficient air-conditioning for small to medium-sized buses
Compact Cooler 8, Cool Top 110 RT-C, Cool Top 140 RT-C, Smirne and Madrid from Webasto primarily cool small to medium-sized buses with up to 35 seats. They have a cooling capacity of 8.5 kW to 15.5 kW and can heat with up to 20 kW. The units are very reliable and durable and can be customized in combination with a wide range of accessories. The air is distributed via a central or two side ducts. The housings of the air-conditioning systems can be painted in the color of the vehicle.
Model Compact Cooler 8
Model Cool Top 110 RT-C/140
Model Smirne
Model Madrid
- Compact Cooler 8
- Cool Top 110/140 RTC right
- Smirne
- Madrid
Benefits of rooftop air-conditioning systems 8.5 - 15.5 kW
Product details
Product specifications
- Cooling capacity from 8.5 to 15.5 kW
- Heating capacity (except Smirne): 7.5 to 20 kW
- Nominal voltage: 12/24 V (Cool Top 110 RT-C: 12 V)
- Dimensions L x W x H (mm) / weight (kg):
- Compact Cooler 8 model: 970 x 1,025 x 197 / 32.0
- Cool Top 110 RT-C model: 1,150 x 1,600 x 204 / 48.0
- Cool Top 140 RT-C model: 1,150 x 1,600 x 204 / 50.0
- Smirne model: 930 x 1,045 x 170 / 33.5
- Madrid model: 1,280 x 1,790 x 185 / 59.0
Model overview
- Compact Cooler 8
- Cool Top 110 RT-C
- Cool Top 140 RT-C
- Smirne
- Madrid
Downloads
Air-conditioning solutions - Catalog
Get the complete catalog of air-conditioning solutions offered by Webasto.
- Size
- 78 MB
- Format
- application/pdf
