Cool Top 120-e
Efficient air-conditioning for electric vehicles
The Cool Top 120-e is a rooftop air-conditioning system designed for electric vehicles such as minibuses, light commercial vehicles and ambulances. Its 12 kW cooling capacity, a variable compressor speed technology and lightweight design make cooling on board efficient, silent, and environmentally friendly. Whether for daily urban use or demanding field service, the Cool Top 120-e creates comfort for various types of electric commercial vehicles.
Benefits of Cool Top 120-e
Product details
Product specifications
- Cooling capacity (nominal): 12kW
- Refrigerant: R1234yf
- Voltage: Compressors: 250 to 460 V DC; Electronics/blowers: 12 V
- Maximum current: 7,5A @ 350V, 83A @ 13,5V
- Max power consumption: High voltage ~2,625 W (compressor), Low voltage ~1,120 W
- Airflow (evaporator blower): ~2,000 m³/h at 475 Pa
- Fans: 2 condenser fans; 2 evaporator blowers, blower are brushless type
- Dimensions (L × W × H): 1,605 × 1,290 × 300 mm
- Weight: approx. 80 kg
- Roof radius radius: 7,000 mm
- Fresh air / recirculation: Included
