Integrated air-conditioning
systems 4 - 5.5 kW

Name: Integrated air-conditioning systems 4 - 5.5 kW
Brand: Webasto
SKU: integrated-air-conditioning-4-55-kw

Jump to section

Benefits Product Details Downloads

Flexible air-conditioning for smaller spaces

These integrated air-conditioning systems from Webasto can be used in a variety of vehicles, for example in minibuses, ambulances and fire engines as well as in construction and agricultural machinery. Depending on the type of vehicle and requirements, they can be installed under the dashboard, in the roof liner under the roof or vertically in the rear panel. The air-conditioning systems are very reliable and durable. The extensive range of accessories allows for an installation in almost any vehicle. The Baltimore, Quebec, Michigan and Milano models also have a heating function.

Webasto Baltimore integrated air-conditioning: compact HVAC module with heat exchanger and dual blowers providing efficient thermal management for EVs.

Model Baltimore

Webasto Oakland integrated A/C unit with evaporator core, dual centrifugal blowers and plug-in harness — part of Webasto's vehicle climate system solutions.

Model Oakland

Webasto Osaka integrated air-conditioning unit with dual adjustable vents, rugged textured casing and mounting flanges for passenger compartment thermal control.

Model Osaka

Webasto Quebec integrated air-conditioning unit for commercial vehicles, compact HVAC with dual top outlets and removable control module for thermal management

Model Quebec

Webasto Montreal integrated air-conditioning system - compact HVAC unit with dual vents and control panel, showcasing Webasto's thermal management solutions.

Model Montreal

Webasto Michigan integrated air-conditioning system; roof-mounted HVAC with dual blowers, six adjustable outlets and controls for vehicle thermal management.

Model Michigan

Webasto Wyoming integrated air-conditioning unit underside with dual centrifugal blowers, six adjustable distribution outlets and vehicle cabin wiring harness.

Model Wyoming

Webasto Milano air-conditioning system: compact HVAC module with dual centrifugal fans and evaporator for efficient thermal management in commercial vehicles.

Model Milano

Benefits of integrated air-conditioning systems 4 - 5.5 kW

Excellent quality

In relation to their size, the integrated air-conditioning units are highly efficient, durable and low-maintenance.

Many installation options

The air-conditioning systems can also be flexibly integrated into various vehicles thanks to a wide range of accessories.

Heating function

The Baltimore, Quebec, Michigan and Milano models have an additional heating function.

Product details

Product specifications

Cooling capacity from 4 to 5.5 kW
Heating capacity (some models): 2 to 11 kW
Nominal voltage: 12/24 V
Dimensions L x W x H (mm) / weight (kg):
- Baltimore and Oakland models: 381 x 233 x 126 / 3.7
- Osaka model: 410 x 165 x 320 / 5.5
- Quebec model: 370 x 185 x 330 / 6.5
- Montreal model: 370 x 160 x 350 / 5.5
- Michigan model: 590 x 380 x 185 / 8.7
- Wyoming model: 590 x 380 x 185 / 7.5
- Milano model: 414 x 328 x 233 / 6.4

Model overview

Baltimore
Oakland
Osaka
Quebec
Montreal
Michigan
Wyoming
Milano
