Kiev
split system
Efficient climate control solution for vehicles requiring maximum cooling and heating power
The Webasto Kiev Horizontal Heating and Cooling Evaporator delivers a powerful 45,500 BTU/h of cooling capacity and 39,000 BTU/h of heating output, making it ideal for applications that demand high-performance climate control. Designed for low-profile, horizontal installation, this unit features variable temperature control and a built-in freeze protection thermostat. Available for both 12 V and 24 V systems, the Kiev Evaporator is versatile and dependable for commercial vehicles operating in extreme conditions.
Discover the advantages of the Kiev split system
The Webasto Kiev Horizontal Heating and Cooling Evaporator is designed to meet the needs of high-demand applications, offering exceptional performance with a cooling capacity of 45,500 BTU/h and a heating output of 39,000 BTU/h. Its low-profile, horizontal design allows for seamless integration into commercial vehicles, ensuring maximum efficiency without compromising interior space. The unit’s variable temperature control provides precise climate management, while the integrated freeze protection thermostat safeguards the system from damage in colder conditions. Compatible with both 12 V and 24 V configurations, the Kiev Evaporator is a robust solution for maintaining optimal climate control in extreme environments.
Product details
Product specifications
Cooling capacity: 45,700 BTU/h (13.4 kW)
Heating capacity: 39,000 BTU/h (11.4 kW)
Refrigerant: R134a
Nominal voltage: 12 V
Max. power consumption (12 V): 34.4 A
Max. air flow Evaporator Blower: 589 cfm (1,000 m³/h)
Dimensions (W x L x H): 33.7 x 14 x 7 in (856 x 355 x 170 mm)
Weight: 27.6 lbs (12.5 kg)
