BlueCool C-Series
Ultra-compact chiller
These standardized Webasto chiller systems are suitable for small and medium-sized boats with several cabins. Whenever three or more independent areas of a yacht need to be air-conditioned, this central cooling system is the right choice.
The extremely compact units in the BlueCool C-Series are usually located in the engine room and supply all cabins with pleasantly cool air via a chilled water circuit and air outlets. They cool with an output of 16,000 to 27,000 BTU/h (4.7 to 7.9 kW) and can also heat via a reverse function. Vibration dampers and soft-start accessories are optionally available.
Benefits of BlueCool C-Series
Product details
Product specification
- Cooling capacity: 16,000 to 27,000 BTU/h (4.7 to 7.9 kW)
- Heating function possible
- Nominal voltage: 230 V
- Frequency: 50/60 Hz
- Dimensions L x W x H (mm) / Dimensions L x W x H (inch) / Weight (kg)
- Type C16 M: 390 x 290 x 355 / 15.4 x 11.4 x 14.0 / 34
- Type C20 M: 440 x 330 x 360 / 17.3 x 13.0 x 14.0 / 37
- Type C27 M: 440 x 330 x 395 / 17.3 x 13.0 x 15.6 / 45
Model overview
- C16 M
- C20 M
- C27 M
| Model overview | Thermo Top Eveo 4 | Thermo Top Evo 5 | Thermo Top Evo 5+* | |||
|---|---|---|---|---|---|---|
| Diesel | Gasoline | Diesel | Gasoline | Diesel | Gasoline | |
| ECE approval number ECE R12 (heating) | E1 00 0258 | E1 00 0258 | E1 00 0258 | |||
ECE approval number ECE R10 | E1 04 5627 | E1 04 5627 | E1 04 5627 | |||
| Heating capacity, part load/ full load (kW) | 2.5/4.0 | 2.8/4.0 | 2.5/5.0 | 2.8/5.0 | 2.5/5.0 | 2.8/5.0 |
| Fuel consumption, part load / full load (l/h) +/- 10% | 0.31/0.49 | 0.39/0.56 | 0.31/0.62 | 0.39/0.70 | 0.31/0.62 | 0.39/0.70 |
| Nominal voltage | 12 | 12 | 12 | |||
| Rated power consumion without coolant pump, part load/ful l load (W) without vehicle’s fan, +/- 10% | 12/21 | 15/21 | 12/33 | 15/33 | 12/33 | 15/33 |
| Fuels | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 |
| Operating temperature range (°C) | -40 to +60 | |||||
| Dimensions L x W x H (mm) | 218 x 91 x 147 | 218 x 91 x 147 | 218 x 91 x 147 | |||
| Weight (kg) | 2.1 | 2.1 | 2.1 | |||
| Coolant pump U4847 Econ | - | |||||
| Volume flow against 0.14 bar (l/h) | 500 | |||||
| Dimensions L x W x H (mm) | 109x49x79 | |||||
| Weight (kg) | 0.3 | |||||
* More details can be found here
