BlueCool SX-Series
Stand-alone air conditioning
Webasto's BlueCool SX-Series standalone air conditioners are the perfect solution for small and medium-sized vessels. Each cabin is equipped with its own cooling unit. In the system, the compressor, condenser, evaporator and blower are pre-assembled on a stainless-steel condensate tray. The compressor is hermetically sealed. The compact systems are designed for 230 V and 115 V environments and cool at up to 27,000 BTU/h. Designed for quiet operation, the systems offer cooling and heating functionality through a reverse-cycle function. It is operated via the innovative MyTouch display, and the evaporator temperature is displayed in real time.
Now available with Intelligent Compressor Control eliminating up to 95% starting peak.
BlueCool SX-Series S10
BlueCool SX-Series S16
BlueCool SX-Series S27
Benefits of BlueCool SX-Series
Product details
Product Specifications
- Cooling capacity: 6,000 - 27,000 BTU/h (1.8 - 7.9 kW)
- Integrated heating via reverse cycle
- Rated voltage: 115 V or 230 V
- Frequency: 50/60 Hz
- Dimensions L x W x H (mm) / Weight (kg)
BlueCool SX-Series 230 V
SX6: 405 x 320 x 315 / 20.5
SX8: 405 x 320 x 315 / 23.5
SX10: 480 x 335 x 315 / 24
SX13: 510 x 350 x 370 / 28.2
SX16: 550 x 350 x 370 / 32
SX20: 590 x 340 x 370 / 36
SX27: 575 x 515 x 410 / 48
BlueCool SX-Series 115 V
SX6: 405 x 320 x 315 / 20.5
SX8: 405 x 320 x 315 / 23.5
SX10: 480 x 335 x 315 / 24
SX13: 510 x 350 x 370 / 28.2
SX16: 550 x 350 x 370 / 32
Model overview
- SX6
- SX8
- SX10
- SX13
- SX16
- SX20 (230 V only)
- SX27 (230 V only)
