BlueCool C-Series
chiller systems
Ultra-compact chiller for marine air-conditioning across multiple cabins
The BlueCool C-Series are ultra-compact chillers designed for yachts requiring air-conditioning across three or more independent areas. With a central control unit and individual cabin panels, they cater to chiller systems from 16,000 BTU/h up to 40,000 BTU/h, making them the ideal solution for diverse cooling needs.
Benefits of BlueCool C-Series chiller systems
The chillers of the BlueCool C-Series boast up to 15 % higher efficiency, continuous cooling even in tropical conditions and a compact design. Enhanced electronics simplify installation and diagnosis via USB, while optional CAN-Bus integration optimizes boat system adaptation.
Technology highlight
Product details
Product specification
The BlueCool C-Series is an ultra-compact basic chiller unit designed for yachts. It features a central control unit, individual cabin panels and a cooling capacity up to 40,000 BTU/h. The C-Series chillers are designed for a voltage of 230 V (50 / 60 Hz). Optional accessories such as soft-start devices and vibration dampers are available.
Model overview
The BlueCool C-Series is tailored for yachts with three or more independent areas needing air-conditioning. With its compact design and advanced features, it is the optimal choice for smaller chiller systems.
What is included
Each BlueCool C-Series unit comes with an outside interface for sensors and displays, a new controller board with a USB-Interface and easy installation mounting brackets. Optional soft-start units are also available.
Model overview | Thermo Top Eveo 4 | Thermo Top Evo 5 | Thermo Top Evo 5+* | |||
---|---|---|---|---|---|---|
Diesel | Gasoline | Diesel | Gasoline | Diesel | Gasoline | |
ECE approval number ECE R12 (heating) | E1 00 0258 | E1 00 0258 | E1 00 0258 | |||
ECE approval number ECE R10 | E1 04 5627 | E1 04 5627 | E1 04 5627 | |||
Heating capacity, part load/ full load (kW) | 2.5/4.0 | 2.8/4.0 | 2.5/5.0 | 2.8/5.0 | 2.5/5.0 | 2.8/5.0 |
Fuel consumption, part load / full load (l/h) +/- 10% | 0.31/0.49 | 0.39/0.56 | 0.31/0.62 | 0.39/0.70 | 0.31/0.62 | 0.39/0.70 |
Nominal voltage | 12 | 12 | 12 | |||
Rated power consumion without coolant pump, part load/ful l load (W) without vehicle’s fan, +/- 10% | 12/21 | 15/21 | 12/33 | 15/33 | 12/33 | 15/33 |
Fuels | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 |
Operating temperature range (°C) | -40 to +60 | |||||
Dimensions L x W x H (mm) | 218 x 91 x 147 | 218 x 91 x 147 | 218 x 91 x 147 | |||
Weight (kg) | 2.1 | 2.1 | 2.1 | |||
Coolant pump U4847 Econ | - | |||||
Volume flow against 0.14 bar (l/h) | 500 | |||||
Dimensions L x W x H (mm) | 109x49x79 | |||||
Weight (kg) | 0.3 |
Downloads
BlueCool C-Series chiller systems - Datasheet
Download the datasheet for the BlueCool C-Series.
- Size
- 667 KB
- Format
- application/pdf
